Proposal
Seat No. | 51+1+1 |
Max. speed | ≥120km/h |
Overall dimensions | 12000*2550*3690mm |
Fuel tank | 400L |
Wheelbase | 6300mm |
Fuel consumption | 22/100(L/km) |
Approach angle | 8° |
Departure angle | 8° |
Min. ground clearance | 205mm |
Min. turning radius | ≤12m |
Body
Wheel cover | Equipped |
Driver position | LHD |
Internal light | Line lights |
Floor mat | Luxury floor mat with quartz sand |
Dashboard | Luxury integrated type |
Side window glass | Upper 1/3 fixed, lower 2/3 sliding window, tempered and dark grey tinted side glass |
Inner luggage rack | Equipped |
Luggage compartment | Max. sapce 9m3, Aluminum alloy flap |
Top hatch & ventilator | 2 sets of top hatch |
Inner trim | Standard |
Passenger door | Auto outward passenger door, front & middle; front door with pneumatic telescopic step |
Passenger seat | 51 Fainsa seats, 2+2 layout, adjustable backrest, transversely moveable, with armrest, foot rest, paper net, food tray, USB charger; 2 point seat belts |
Guide seat | Equipped |
Driver seat | Leather driver seat with air suspension |
Safety belt | All seats with safety belt |
Front sun visor | Sun visor for driver and guide |
Rear view mirror | Standard electric type |
Vehicle ID | English Vehicle ID |
Color & pattern | As per customer needs |
Painting | Standard |
Curtain | Equipped |
Chassis
Engine | CUMMINS L360 20 (EURO II), Displacement: 8.9L, six cylinder, diesel engine Max power: 264kW/2200rpm Max torque: 1480 N.m /1440rpm |
Gearbox | Chinese transmission, Manual, six gear |
Clutch | SACHS, diameter: 430mm Dry single plate with cushioning springs, hydraulic with air assisted |
Front Axle | Dongfeng, 6.5T, reverse Elliot, I-beam |
Rear Axle | Dongfeng, 13T, spiral bevel pinion and hypoid gear semi-floating |
Suspension | Leaf spring, front 10/rear12, hydraulic double acting telescopic shock absorbers |
Steering | BOSCH Power steering |
Brake | Full air brake, front & rear drum type |
Retarder | Equipped |
Tyre | 295/80R22.5 tubeless tyre |
ABS & Auto slack adjuster | Equipped |
Electrical Equipment
Alternation | Prestolite alternator |
Battery | 200Ah*2 |
Electric/pneumatic horn | Equipped |
Digital clock | Equipped |
CAN | Chinese CAN-controller area network |
High position brake lamp | Equipped |
Audio-vision system | DVD player + front 22 inch fixed LCD & middle 19 inch fixed LCD |
A/C | Songz brand, 32000Kcal/h, Bitzer compressor |
Fire extinguisher | Automatic fire extinguishers in engine compartment |
Rear view mirror | Equipped |
Defroster | Equipped |
WIFI device | Equipped |
Reversing buzzer | Equipped |
Reversing monitor | Color reversing monitor |
