Power system
Engine positon | Rear-mounted |
Engine model | ISF3.8s5141 oV |
Engine type | In-line,4-cylinders,four-stroke,super-charged and mid-cooling |
Manufacturer | Cummins |
Fuel | Diesel |
Displacement(L) | 3.76 |
Rated power(kw) | 102Kw@2600rpm |
Max torque(N.M) | 440N.m@1200-2200rpm |
Main body composition
Gearbox | Allison T2100 |
Steering | Ball circuit power steering |
Tyre | 215/75R17.5 |
Supension | Air suspension |
Basic parameter
Length*Width*Height(mm) | 7900*2050*3000 |
Wheel base(mm) | 3900 |
Tread front/rear(mm) | 1547/1725 |
F/R overhang(mm) | 1680/2320 |
Passengers | 32+1 |
Vehicle performance parameters
Max speed(km/h) | 100 |
Max G.V.W(kg) | 8300 |
Curb weight | 5500 |
Create Values and Win Reputation with Services
People Oriented, Customer Foremost. Refined high performance products, diversified sales channels as well as professional and consummated service system are three integral parts of the same importance. The Customer Service Department tailors considerate services for the customers.
Whole Life Cycle Service
Pay a return visit within three months after the purchase of the new vehicle. Establish customer archive and notify the customers for maintenance issues in a scheduled manner.
R&D
We have achieved 23 national patents for new energy vehicles by so far. The technology and products have been recognized by the national authoritative inspection institutions and the scientific and technological departments, and the performance of the whole vehicle is good. What is more, a number of core indexes have reached " the international advanced level "in terms of power performance.
The Largest Service Team In The Industry
SHANGRAO COACH has the largest first-line market service team in the industry, providing customers with maintenance, accessories and technical services at any time.
